Introducing
Orbimax MXi Series Industrial Grade TIG Welders
Designed for the welder, by the welder.
Orbimax MXi P300 Smart
Our top of the range Smart Industrial Grade Pulse MIG Welders sets you up for the future of welding. Fully equipped with every welding process including Focus-arc and Focus-root, this machine will take you to the pinnacle of welding.
- Welding current: DC
- Process: MIG + MAG
- Welding range: 20-310A
- Power: 415V 3PH
- Duty cycle: 100% @ 280A
- Protection type: IP 23
- Seperate wire feed
Downloads
ORBIMAX
Weld Smarter
With maximum efficiency
SMART + SIMPLE
Orbimax Industrial MIG Welders are Smart + Simple, designed with the future of welding in mind, but with simplicity at the core.
German made and refined for the Australian welding industry, the Orbimax MXi Series are designed for serious fabrication workshops where quality, efficiency and productivity are paramount.
SAVE TIME AND MONEY
MXi Series MIG welders put the welder in control, improving weld quality while reducing spatter, fumes and the need for rework.
EDGE
Our intermediate Pulse MIG welders give you the edge. The Smart and Simple Edge Series welders are equipped with everything the professional welder requires. Optimised for increased functionality, mobility and key features to perfect your weld.
SMART
Our top of the range Smart Industrial Grade Pulse MIG welders set you up for the future of welding. Fully equipped with every welding process, including Focus Arc and Focus Root, this machine will take you to the pinnacle of welding. The Orbimax Smart range is designed for professional use- designed by welders, for welders.
SETTING THE STANDARD IN MODERN MIG WELDING.
WELD FASTER WITH BETTER QUALITY
The MXi Series industrial MIG welders introduce exclusive Focus Arc (only on MXi Smart Model) technology, letting you weld up to 30% faster with a short, powerful regulated arc improving weld quality, reducing spatter, fumes, and the need for rework.
When combined with Stepless Dynamic Inductance you have precise control of the arc length, which not only measures the arc voltage and welding current but also digitally monitors the wire feed speed, all meaning you can weld faster with better quality.
REDUCE REWORK
With controlled heat input, improved visibility and more control of the welding arc, less faults occur which means less rework.
SAFER WORKING ENVIRONMENT
Create a safer working environment with up to 70% reduction in toxic welding fumes.
Key Features
FOCUS ARC
Increase productivity with higher deposition rates. Welding with a short, powerfu arc, improving quality, visibility, arc control and reducing faults. (Excludes base mode MX 251.)
POWER PULSE
Power Pulse is ideal for welding steel, stainless steel and aluminium at a faster rate - giving you a TIG like seam surface while reducing temper colour.
FOCUS ROOT
Focus Root provides a spatter-free welding process ideal for thin sheets and root welds. Perfect for bridging gaps faster with less spatter. (Only available on MXi Smart models).
SIRIUS OPERATING SYSTEM
Digital integration with display that shows everything at a glance, relevant parameters are always in the foreground, which can be recognised from a distance by the operator. Provides easy integration into CAD and ERP systems.
STEPLESS DYNAMIC INDUCTANCE (SDI)
SDI allows for fine-tuning of the arc, ideal for welding thin materials.
PENETRATION STABILISER
Detects changes and automatically corrects arc power, resulting in a uniform penetration when welding out of position.
SMART MACHINE CONTROL (SMC)
Provides intelligent control of the welding machine, leading to excellent welding results and improved efficiency.
MAINS VOLTAGE COMPENSATION
The Orbimax MXi Range automatically detects fluctuations in the mains voltage and adjusts the wire feeder accordingly.
DUTY CYCLE
Best in class industry-leading duty cycle of 100% @ 280A (MXi-P 300) and 100% @ 400A (MXi-P 450).
WATER COOLED OPTION
Choose from a water cooled or gas cooled option across the range.
POWER FACTOR CONTROLLOR (PFC)
PFC corrects phase shifting as well as peaks in the currents. This ensures current consumption is regulated according to the voltage at each moment, resulting in reduced power consumption.
CONTINUOUSLY ADJUSTABLE
Continuously adjustable for perfect MIG/MAG welding results.
MORE USER FRIENDLY
Simplified operation of processes, with easy-to-use navigation.
