COBOT: Collaborative Robot Welding

MAKE IT WITH ORBIMAX

High-performance Collaborative Welding Robots for precision workshop automation.

Automated Cobot Welding

Automating high-quality welds is no longer restricted to large-scale automotive assembly lines. Our collaborative welding robots (COBOT), integrate advanced robotic arms with professional welding power sources to execute precise, automated welds. By automating repetitive linear, circular, and multi-axis joint paths, a robotic welder increases workshop productivity and maintains flawless quality, allowing certified welders to focus on complex assemblies and setup configurations.

Simple Programming & Setup

Traditional industrial robots require complex coding, specialised software training, and lengthy setup times. In contrast, our automated cobot welders feature intuitive hand-guiding (lead-through) programming and easy-to-use touchscreen interfaces. Operators can teach the robot new weld paths in minutes by simply guiding the torch manually to the start, path, and end positions, making it highly efficient for low-volume, high-mix job shop operations.

High-Precision Repeatability

Weld consistency and speed are critical to maintaining margins in metal fabrication. With sub-millimeter positioning accuracy, our cobot welding systems deliver identical weld profiles, uniform penetration, and perfect heat control across every single piece. This high-precision repeatability minimises scrap metal waste, eliminates grinding and rework, reduces operator physical fatigue, and ensures that all outputs meet stringent structural codes.

UR10 COBOT Package
UR10 COBOT Package
Collaborative Welding Robot (Cobot)
UR10 COBOT Package
UR10 COBOT Package
UR10 COBOT Package
UR10 COBOT Package
UR10 COBOT Package
UR10 COBOT Package
UR10 COBOT Package
UR10 COBOT Package
UR10 COBOT Package
UR10 COBOT Package
UR10 COBOT Package
UR10 COBOT Package
UR10 COBOT Package
UR10 COBOT Package
UR10 COBOT Package
UR10 COBOT Package
UR10 COBOT Package
UR10 COBOT Package
UR10 COBOT Package
Collaborative Welding Robot (Cobot)
UR10 COBOT Package
UR10 COBOT Package
UR10 COBOT Package
UR10 COBOT Package
UR10 COBOT Package
UR10 COBOT Package
UR10 COBOT Package
UR10 COBOT Package
UR10 COBOT Package
UR10 COBOT Package
UR10 COBOT Package
UR10 COBOT Package
UR10 COBOT Package
UR10 COBOT Package
UR10 COBOT Package
UR10 COBOT Package
UR10 COBOT Package
UR10 COBOT Package

Orbimax

UR10 COBOT Package

$0.00 Ex GST Sale • Save

Compact, versatile, and built for precision, the COBOT UR10 Package is designed to streamline welding operations and improve productivity across a wide range of applications.

Ideal for workshops looking to increase weld consistency and reduce manual labour, the UR10 offers an efficient automation solution without the complexity of traditional robotic systems. Secure this package during the EOFY Runout Campaign and take the next step towards smarter welding automation.

Address Skilled Welder Shortages & Scale Your Production Output

Keep your welding booths running and increase your workshop's throughput. The Collaborative Welding Robot (Cobot Welder) integrates a high-precision collaborative robot manipulator with professional synergic welding power sources (such as Fronius or Miller). It is designed to act as an automated tool in your welders' toolbox, taking care of high-mix, repetitive runs so your skilled fabricators can focus on complex preparation and specialty custom jobs.

Typical Applications & Industries:

  • High-Mix, Low-Volume Shops: Set up and automate small batches and repeat parts in minutes.
  • Structural Steel & Fabrication: Consistent multi-pass and high-performance MIG/Pulsed MIG preps.
  • Repetitive Sub-Assemblies: Reliable, code-compliant weld profiles that reduce rework and post-weld clean-up to zero.

Zero Programming

Welders register weld points directly by hand-guiding the torch in Gravity-Free mode and saving positions on the Smart Puck.

App-Based Parameters

Adjust travel speed, wire feed, and weaving configurations instantly on a phone or tablet using the intuitive control app.

Fast Deployment

Shipped fully assembled on a mobile cart with a grid table. Roll into position, connect power and gas, and start welding.

Cobot Welder Brochure

Compatible Consumables

What's Included (Full Turn-key Package)

The Orbimax Collaborative Welding Robot is delivered as a complete, ready-to-weld package.

1
Universal Robots Collaborative Arm
Available as a UR10e (1.3m reach) or UR20e (1.75m reach) arm. Exceeds standard robotic quality and safety expectations.
2
Miller Invision 352 MPa Power Source
Pulse MIG synergic welder providing excellent arc performance critical for steel, stainless steel, and aluminium.
3
Siegmund Welding Table
Industry-tough 1200mm x 812mm (System 16 grid) table, renowned for strength, precision, and quick setups.
4
Tregaskiss CA3 MIG Torch (Tough Gun)
Air-cooled robotic MIG torch engineered for high-volume durability, precision, and minimal downtime.
5
COBOT Control App
Smart, simple touch interface designed for any operator. No complex programming or robotic coding needed.
6
Welder Control Panel
Simple interface for operators to easily start, stop, and pause preset weld programs instantly.

Operational Benefits & Capabilities

  • Smart Puck Teaching: Move the robot by hand-guiding to register welds directly at the torch head—no programming pendants or complex code required.
  • App-Controlled Parameters: Easily customize travel speeds, weave frequencies, dwell times, and amplitudes on a smartphone or tablet app.
  • Collaborative Design (Cage-Free): High-sensitivity force-sensing torque sensors at each joint halt motion instantly on physical contact, allowing safe operation alongside your team.
  • Synergic Welding Interface: Integrates directly with professional wire feeders and synergic power sources to automate voltage and feed rate adjustments on the fly.
  • Mobile Cart Integration: Heavy-duty industrial welding base with caster wheels makes it easy to move the cobot from bay to bay to meet changing workshop demands.

System Technical Specifications

Welding Power Source Miller Invision 352 MPa Pulse MIG Welder
Duty Cycle Rating 60% @ 350 Amps | 100% @ 300 Amps
Manipulator Reach Radius UR10e (1300 mm reach) or UR20e (1750 mm reach)
Positional Repeatability ±0.03 mm (high-precision pose accuracy)
Travel Velocity Range 1 to 80 Inches Per Minute (IPM)
Fixture Grid Table Siegmund System 16 (1200 mm x 812 mm)

Interactive Weld Parameter Simulator

Select joint settings below to calculate dynamic weld parameter recommendations.
3.2 mm
Weld Travel Velocity 18.5 IPM
Wire Feed Velocity 280 IPM
Recommended Voltage 19.5 V
Recommended Gas Flow 15 L/min
Est. Cycle Time (per 300mm) 38.4 sec

Video Demonstrations & Case Studies

Watch the Collaborative Welding Robot in action and learn about setups and programming.
Orbimax Collaborative Welding Robot (Cobot) - Overview
Orbimax Collaborative Welding Robot (Cobot) - Overview ▶
Orbimax Collaborative Welding Robot (Cobot) - Overview
How to Set Up a New Welding Job with the Beacon App ▶
How to Set Up a New Welding Job with the Beacon App
Lesson 1: How to Program a Welding Robot in Minutes ▶
Lesson 1: How to Program a Welding Robot in Minutes
Testimonial | Industrial Manufacturing Services (IMS) ▶
Testimonial | Industrial Manufacturing Services (IMS)

System Capabilities & Applications

See what the collaborative welding system can accomplish for your business from precision processes to flexible production runs.

Welding Automation

Take the complexity out of automation. Our cobot welding solutions deliver consistent, high‑quality welds with minimal setup, empowering your team to boost productivity without needing a dedicated robotics expert.

MIG Welding

From thick plate to thin gauge, our cobot MIG welding configuration is built for speed, repeatability, and ease, helping you meet demand and maintain quality without manual strain.

TIG Welding

Our robotic systems deliver the precision and consistency you expect from TIG, but with a faster setup and simpler operation. Eliminate bottleneck weld stations while keeping quality high.

Plasma Cutting

Our cobot-powered plasma cutting system delivers clean, accurate cuts on day one, without complex CNC programming, gantry space, or bulky equipment setups.

High-Volume Production

Scale your output with ease. Our cobot solutions are designed to handle high-volume workflows with consistent quality, minimal downtime, and rapid job changeovers.

Low-Volume, High-Mix

Ideal for short runs and quick-turn projects. Our cobots give you the flexibility to efficiently weld small batches and prototypes without reprogramming or long setup times.

Frequently Asked Questions

Find answers to common questions about collaborative welding robots and how they integrate into manufacturing workshops.
Who is cobot welding for? +

The Cobot Welder is built for fabrication workshops, contract manufacturers, and OEMs that need reliable welding output without the cost and complexity of traditional robotic welding cells. If you’re struggling to find skilled welders, dealing inconsistent manual weld quality, or turning down work because you can’t keep up with demand, cobot welding fills the gap. It’s especially effective for shops running a mix of short-run and repeat jobs, reprogram in minutes, not days.

What kind of ROI can the Cobot Welder provide for my business? +

Depending on your production factors, cobots can 2–10X your fabrication productivity. Most shops see 2–4X the production output, saving them significant labor hours and freeing their staff to work manually on tasks that matter the most.

Can I weld aluminum with the Cobot Welder? +

Yes, you can. Just like you would MIG weld aluminum manually, with a few settings and accessory adjustments, you can produce high-quality aluminum welds with the Cobot Welder.

Will Cobot Welder weld my parts? +

Our Cobot Welder can complete most repetitive welding tasks, but part suitability depends on the part size, material type, and more. The best way to know for sure is to reach out to us for a demo so we can best assess your application needs.

How fast can I weld with a Cobot Welder? +

The cobot’s maximum speed is approximately 39 inches per second (1 meter). When welding, the Cobot Welder can weld up to 90 inches per minute. This is extremely fast, far faster than a human can weld, giving you extremely low heat input and maximum productivity.

Can I replace manual TIG welding with the Cobot Welder? +

Yes! Orbimax customers have achieved TIG-quality welds with the Cobot Welder using MIG processes. One client sped up their TIG welding from 2–5 inches per minute up to 20 inches per minute, enabling them to clear their backlog in just a few weeks.

Do I need to buy the Cobot Welder to see if my fab shop will benefit from it? +

No, you don’t need to buy upfront. After a demonstration, you can enter Orbimax’s rent-to-own program and fully commit once you are ready. This lets you validate the cobot’s performance in your shop before making a full purchase.

What do I need to know about safety when cobot welding? +

While cobots have numerous safety features built in and do not require safety cages like traditional automation, there are important safety items to keep in mind. Most importantly, your welders need proper PPE just like manual welding. You’ll also want arc flash protection for nearby workers, and fume extraction is essential.
